Ref	Part #	Item	Price
010	K3531-56100	ASSY ARM, REAR AXLE	$1,340.46
020	78620-31510	BUSH, 30MM	$7.59
030	06613-10675	NIPPLE, GREASE	$2.34
040	K3351-56000	ASSY HOLDER F ***	$139.69
060	37410-56180	COLLAR, THRUST	$10.64
070	37410-56150	BUSHING	$19.35
080	04816-50450	O-RING	$2.37
100	6C040-56170	COMP BOLT	$3.05
120	K3531-56133	ASSY HOLDER,REAR AXLE ***	$148.52
130	K3511-56144	HOLDER	$91.93
140	6C040-56150	COLLAR, THRUST	$6.71
150	K3531-56170	BUSHING	$33.30
160	04811-50600	O RING *	$1.98
170	38630-44840	PLUG	$9.26
180	K3531-56160	PIN, KING	$181.41
190	K3531-56250	COLLAR THRUST	$34.30
200	K3531-56232	ARM,KNUCKLE LH	$161.09
200	K3531-56232	ARM,KNUCKLE LH	$161.09
210	K3651-56220	ARM, KNUCKLE RH	$159.69
210	K3650-56220	ARM,KNUCKLE	$232.22
220	01173-51060	BOLT M10x1.25x60 mm ***	$2.07
230	02118-50100	NUT, HEX 4T M10X1.25 (CRP SPD KIT) ***	$0.99
240, 295	04512-50100	WASHER,M10 SPRING LOCK ***	$0.99
250	K3531-56502	ASSY ROD,TIE *	$194.52
250	K3650-56550	ASSY ROD,TIE	$174.19
260	67121-56560	COVER, DUST	$9.26
270	67121-56570	CLIP, DUST COVER	$1.32
280	66591-56780	NUT	$4.13
290	05511-52520	PIN,SPLIT ***	$0.99
300	01133-51440	BOLT M14x1.5x40 mm ***	$2.33
320	01517-51440	STUD ***	$2.60
330	04512-50140	WASHER, SPRING ***	$0.99
340	02174-50140	NUT, HEX M14-1.5 ***	$1.00

Ref: 010 Part #: K3531-56100 Price: $1,340.46

Item: ASSY ARM, REAR AXLE

QTY:

Ref: 020 Part #: 78620-31510 Price: $7.59

Item: BUSH, 30MM

QTY:

Ref: 030 Part #: 06613-10675 Price: $2.34

Item: NIPPLE, GREASE

QTY:

Ref: 040 Part #: K3351-56000 Price: $139.69

Item: ASSY HOLDER F ***

QTY:

Ref: 060 Part #: 37410-56180 Price: $10.64

Item: COLLAR, THRUST

QTY:

Ref: 070 Part #: 37410-56150 Price: $19.35

Item: BUSHING

QTY:

Ref: 080 Part #: 04816-50450 Price: $2.37

Item: O-RING

QTY:

Ref: 100 Part #: 6C040-56170 Price: $3.05

Item: COMP BOLT

QTY:

Ref: 120 Part #: K3531-56133 Price: $148.52

Item: ASSY HOLDER,REAR AXLE ***

QTY:

Ref: 130 Part #: K3511-56144 Price: $91.93

Item: HOLDER

QTY:

Ref: 140 Part #: 6C040-56150 Price: $6.71

Item: COLLAR, THRUST

QTY:

Ref: 150 Part #: K3531-56170 Price: $33.30

Item: BUSHING

QTY:

Ref: 160 Part #: 04811-50600 Price: $1.98

Item: O RING *

QTY:

Ref: 170 Part #: 38630-44840 Price: $9.26

Item: PLUG

QTY:

Ref: 180 Part #: K3531-56160 Price: $181.41

Item: PIN, KING

QTY:

Ref: 190 Part #: K3531-56250 Price: $34.30

Item: COLLAR THRUST

QTY:

Ref: 200 Part #: K3531-56232 Price: $161.09

Item: ARM,KNUCKLE LH

QTY:

Ref: 200 Part #: K3531-56232 Price: $161.09

Item: ARM,KNUCKLE LH

QTY:

Ref: 210 Part #: K3651-56220 Price: $159.69

Item: ARM, KNUCKLE RH

QTY:

Ref: 210 Part #: K3650-56220 Price: $232.22

Item: ARM,KNUCKLE

QTY:

Ref: 220 Part #: 01173-51060 Price: $2.07

Item: BOLT M10x1.25x60 mm ***

QTY:

Ref: 230 Part #: 02118-50100 Price: $0.99

Item: NUT, HEX 4T M10X1.25 (CRP SPD KIT) ***

QTY:

Ref: 240295 Part #: 04512-50100 Price: $0.99

Item: WASHER,M10 SPRING LOCK ***

QTY:

Ref: 250 Part #: K3531-56502 Price: $194.52

Item: ASSY ROD,TIE *

QTY:

Ref: 250 Part #: K3650-56550 Price: $174.19

Item: ASSY ROD,TIE

QTY:

Ref: 260 Part #: 67121-56560 Price: $9.26

Item: COVER, DUST

QTY:

Ref: 270 Part #: 67121-56570 Price: $1.32

Item: CLIP, DUST COVER

QTY:

Ref: 280 Part #: 66591-56780 Price: $4.13

Item: NUT

QTY:

Ref: 290 Part #: 05511-52520 Price: $0.99

Item: PIN,SPLIT ***

QTY:

Ref: 300 Part #: 01133-51440 Price: $2.33

Item: BOLT M14x1.5x40 mm ***

QTY:

Ref: 320 Part #: 01517-51440 Price: $2.60

Item: STUD ***

QTY:

Ref: 330 Part #: 04512-50140 Price: $0.99

Item: WASHER, SPRING ***

QTY:

Ref: 340 Part #: 02174-50140 Price: $1.00

Item: NUT, HEX M14-1.5 ***

QTY:

KUBOTA F2680E PARTS REAR AXLE REAR WHEEL G13000 REAR AXLE
