Ref	Part #	Item	Price
010	TC630-29922	COMP STEP * ***	$391.79
020	TC402-47470	STEP,AID LH	$206.17
030	01754-50812	BOLT M8x1.25x12 mm ***	$2.59
040	TC403-42760	COVER,ACCEL PEDAL	$7.74
050	TC430-29160	BRACKET,STEP FRON.LH	$66.70
060, 080	01133-51230	BOLT M12x1.25x30 mm ***	$1.55
070	TC432-29152	BRACKET,STEP FRONT RH	$90.17
090	TC422-47380	CUSHION	$13.98
100	TC683-17980	RUBBER,ANTIVIB STEP * *	$2.04
110	TC582-47320	WASHER,MOUNT	$2.91
120	01173-51660	BOLT M16x1.5x60 mm	$2.47
130	04512-70160	WASHER,SPRING	$0.99
140	02174-50160	NUT,HEX M16x2 4T JIS ***	$1.49
150	04011-50160	WASHER, PLAIN PTD ***	$0.99

Ref: 010 Part #: TC630-29922 Price: $391.79

Item: COMP STEP * ***

QTY:

Ref: 020 Part #: TC402-47470 Price: $206.17

Item: STEP,AID LH

QTY:

Ref: 030 Part #: 01754-50812 Price: $2.59

Item: BOLT M8x1.25x12 mm ***

QTY:

Ref: 040 Part #: TC403-42760 Price: $7.74

Item: COVER,ACCEL PEDAL

QTY:

Ref: 050 Part #: TC430-29160 Price: $66.70

Item: BRACKET,STEP FRON.LH

QTY:

Ref: 060080 Part #: 01133-51230 Price: $1.55

Item: BOLT M12x1.25x30 mm ***

QTY:

Ref: 070 Part #: TC432-29152 Price: $90.17

Item: BRACKET,STEP FRONT RH

QTY:

Ref: 090 Part #: TC422-47380 Price: $13.98

Item: CUSHION

QTY:

Ref: 100 Part #: TC683-17980 Price: $2.04

Item: RUBBER,ANTIVIB STEP *** ***

QTY:

Ref: 110 Part #: TC582-47320 Price: $2.91

Item: WASHER,MOUNT

QTY:

Ref: 120 Part #: 01173-51660 Price: $2.47

Item: BOLT M16x1.5x60 mm

QTY:

Ref: 130 Part #: 04512-70160 Price: $0.99

Item: WASHER,SPRING

QTY:

Ref: 140 Part #: 02174-50160 Price: $1.49

Item: NUT,HEX M16x2 4T JIS ***

QTY:

Ref: 150 Part #: 04011-50160 Price: $0.99

Item: WASHER, PLAIN PTD ***

QTY:

KUBOTA L4701DT PARTS HOOD BONNET L22500 STEP
