KUBOTA | Buy Direct | Order Online

Ref	Part #	Item	Price
010	3F240-93010	BAR	$313.48
020	3T400-93020	SUPPORT, BAR RH	$250.99
030	3T400-93030	SUPPORT, BAR LH	$248.02
040	04816-50450	O-RING	$2.37
050	36530-93040	STUD	$11.32
060	02176-50140	NUT	$1.00
070	01176-51402	BOLT M14x1.5x110 mm	$3.18
080	04512-50140	WASHER, SPRING ***	$0.99
090	35707-49153	STUD, WHEEL	$16.92
100	02176-50160	NUT, HEX	$1.49
110	04512-70160	WASHER,SPRING	$0.99
120	36530-93060	BUSH	$142.27
130	04611-00470	CIR-CLIP, INTERNAL	$1.94
140	36530-93070	SPACER	$6.94
150	36530-93082	SEAL, OIL	$12.34
160	36530-93094	STOPPER	$29.82
170	33860-93142	COLLAR, THRUST	$5.66
180	36910-93140	COLLAR, THRUST	$4.36
190	36530-93110	CIR-CLIP	$2.23
200	36530-93120	COLLAR	$21.57
210	33860-93132	COLLAR (DETECTOR BAR 1)	$52.28
220	3M740-93150	NUT ***	$15.20
230	05511-50540	PIN, SPLIT ***	$0.99

Ref: 010 Part #: 3F240-93010 Price: $313.48

Item: BAR

QTY:

Ref: 020 Part #: 3T400-93020 Price: $250.99

Item: SUPPORT, BAR RH

QTY:

Ref: 030 Part #: 3T400-93030 Price: $248.02

Item: SUPPORT, BAR LH

QTY:

Ref: 040 Part #: 04816-50450 Price: $2.37

Item: O-RING

QTY:

Ref: 050 Part #: 36530-93040 Price: $11.32

Item: STUD

QTY:

Ref: 060 Part #: 02176-50140 Price: $1.00

Item: NUT

QTY:

Ref: 070 Part #: 01176-51402 Price: $3.18

Item: BOLT M14x1.5x110 mm

QTY:

Ref: 080 Part #: 04512-50140 Price: $0.99

Item: WASHER, SPRING ***

QTY:

Ref: 090 Part #: 35707-49153 Price: $16.92

Item: STUD, WHEEL

QTY:

Ref: 100 Part #: 02176-50160 Price: $1.49

Item: NUT, HEX

QTY:

Ref: 110 Part #: 04512-70160 Price: $0.99

Item: WASHER,SPRING

QTY:

Ref: 120 Part #: 36530-93060 Price: $142.27

Item: BUSH

QTY:

Ref: 130 Part #: 04611-00470 Price: $1.94

Item: CIR-CLIP, INTERNAL

QTY:

Ref: 140 Part #: 36530-93070 Price: $6.94

Item: SPACER

QTY:

Ref: 150 Part #: 36530-93082 Price: $12.34

Item: SEAL, OIL

QTY:

Ref: 160 Part #: 36530-93094 Price: $29.82

Item: STOPPER

QTY:

Ref: 170 Part #: 33860-93142 Price: $5.66

Item: COLLAR, THRUST

QTY:

Ref: 180 Part #: 36910-93140 Price: $4.36

Item: COLLAR, THRUST

QTY:

Ref: 190 Part #: 36530-93110 Price: $2.23

Item: CIR-CLIP

QTY:

Ref: 200 Part #: 36530-93120 Price: $21.57

Item: COLLAR

QTY:

Ref: 210 Part #: 33860-93132 Price: $52.28

Item: COLLAR (DETECTOR BAR 1)

QTY:

Ref: 220 Part #: 3M740-93150 Price: $15.20

Item: NUT ***

QTY:

Ref: 230 Part #: 05511-50540 Price: $0.99

Item: PIN, SPLIT ***

QTY:

KUBOTA M6 131DTC PARTS HYDRAULIC SYSTEM J33400 DETECTOR BAR (BAR BAR SUPPORT)
