Ref	Part #	Item	Price
010	TC350-58634	CASE,BRAKE LH	$665.52
020	05012-01018	PIN, STRAIGHT	$1.00
030	01574-51265	STUD	$2.60
040	01574-51240	STUD ***	$1.94
050	01574-51250	STUD *	$1.94
060	01133-51235	BOLT M12x1.25x35 mm ***	$1.63
070	01133-51240	BOLT M12x1.25x40 mm ***	$1.68
080	TA150-28912	STUD	$6.34
090, 180	04512-50120	WASHER, SPRING LOCK ***	$1.70
100	T3680-80950	NUT,M12,CR	$1.65
110	TC350-27360	NUT,M12,H,CR	$1.65
120	04811-10120	O-RING	$1.24
130	34070-24190	BOLT	$1.11
140	15471-96650	GASKET, COPPER *	$1.14
150	34070-28716	CAM, BRAKE LH	$93.77
160	04816-00220	O-RING	$2.08
170	04015-50120	WASHER, PLAIN ***	$0.99
190	T3630-80990	NUT,M12,4T,CR	$1.28
200	T1890-28770	PLATE,BRAKE CAM LH	$130.80
210	07715-00805	BALL, BRAKE	$1.07
220	TD170-28200	BRAKE, DISK MAIN	$87.52
230	37720-28170	PLATE, BRAKE	$40.24
240	34070-44615	LEVER, BRAKE CAM LH	$112.75

Ref: 010 Part #: TC350-58634 Price: $665.52

Item: CASE,BRAKE LH

QTY:

Ref: 020 Part #: 05012-01018 Price: $1.00

Item: PIN, STRAIGHT

QTY:

Ref: 030 Part #: 01574-51265 Price: $2.60

Item: STUD

QTY:

Ref: 040 Part #: 01574-51240 Price: $1.94

Item: STUD ***

QTY:

Ref: 050 Part #: 01574-51250 Price: $1.94

Item: STUD *

QTY:

Ref: 060 Part #: 01133-51235 Price: $1.63

Item: BOLT M12x1.25x35 mm ***

QTY:

Ref: 070 Part #: 01133-51240 Price: $1.68

Item: BOLT M12x1.25x40 mm ***

QTY:

Ref: 080 Part #: TA150-28912 Price: $6.34

Item: STUD

QTY:

Ref: 090180 Part #: 04512-50120 Price: $1.70

Item: WASHER, SPRING LOCK ***

QTY:

Ref: 100 Part #: T3680-80950 Price: $1.65

Item: NUT,M12,CR

QTY:

Ref: 110 Part #: TC350-27360 Price: $1.65

Item: NUT,M12,H,CR

QTY:

Ref: 120 Part #: 04811-10120 Price: $1.24

Item: O-RING

QTY:

Ref: 130 Part #: 34070-24190 Price: $1.11

Item: BOLT

QTY:

Ref: 140 Part #: 15471-96650 Price: $1.14

Item: GASKET, COPPER *

QTY:

Ref: 150 Part #: 34070-28716 Price: $93.77

Item: CAM, BRAKE LH

QTY:

Ref: 160 Part #: 04816-00220 Price: $2.08

Item: O-RING

QTY:

Ref: 170 Part #: 04015-50120 Price: $0.99

Item: WASHER, PLAIN ***

QTY:

Ref: 190 Part #: T3630-80990 Price: $1.28

Item: NUT,M12,4T,CR

QTY:

Ref: 200 Part #: T1890-28770 Price: $130.80

Item: PLATE,BRAKE CAM LH

QTY:

Ref: 210 Part #: 07715-00805 Price: $1.07

Item: BALL, BRAKE

QTY:

Ref: 220 Part #: TD170-28200 Price: $87.52

Item: BRAKE, DISK MAIN

QTY:

Ref: 230 Part #: 37720-28170 Price: $40.24

Item: PLATE, BRAKE

QTY:

Ref: 240 Part #: 34070-44615 Price: $112.75

Item: LEVER, BRAKE CAM LH

QTY:

KUBOTA MX5400DT PARTS REAR AXLE BRAKE E16100 BRAKE LH
