KUBOTA | Buy Direct | Order Online

Ref	Part #	Item	Price
010	K3411-16520	ARM, SHIFT	$44.27
020	05411-00630	PIN, SPRING	$1.00
030	K3411-42023	ASSY ROD, CONTROL *	$46.49
040	K3811-42022	ASSY ROD, CONTROL ***	$28.57
050	K3811-42160	END,ROD,M8X1.25 ***	$12.82
060	K3411-42172	ROD CONTROL *	$12.34
070	K3811-42100	NUT,HEX M8x1.25 LH ***	$0.99
080	K3811-42190	NUT,M8X1.25 ***	$1.72
090	01754-50835	BOLT M8x1.25x35 mm ***	$3.63

Ref: 010 Part #: K3411-16520 Price: $44.27

Item: ARM, SHIFT

QTY:

Ref: 020 Part #: 05411-00630 Price: $1.00

Item: PIN, SPRING

QTY:

Ref: 030 Part #: K3411-42023 Price: $46.49

Item: ASSY ROD, CONTROL *

QTY:

Ref: 040 Part #: K3811-42022 Price: $28.57

Item: ASSY ROD, CONTROL ***

QTY:

Ref: 050 Part #: K3811-42160 Price: $12.82

Item: END,ROD,M8X1.25 ***

QTY:

Ref: 060 Part #: K3411-42172 Price: $12.34

Item: ROD CONTROL *

QTY:

Ref: 070 Part #: K3811-42100 Price: $0.99

Item: NUT,HEX M8x1.25 LH ***

QTY:

Ref: 080 Part #: K3811-42190 Price: $1.72

Item: NUT,M8X1.25 ***

QTY:

Ref: 090 Part #: 01754-50835 Price: $3.63

Item: BOLT M8x1.25x35 mm ***

QTY:

KUBOTA ZD1011 PARTS MOTION CONTROL LEVER F14700 MOTION CONTROL ARM
