Ref	Part #	Item	Price
1	2864	WASHER, FLAT, 3/4, ZINC-PLT STL	$0.99
2	4181	.781 X 1.00 X .500 HT SLV	$3.75
3	4207	Arm, subassembly	Call for price
4	1285	PIN, COTTER 1/4 X 1-1/2	$1.44
5	12243	59ETC CASTER YK W/AXLE	$119.49
6	4212	Axle assembly	Call for price
7	1266	PIN, COTTER 3/16 X 1-1/2	$1.44
8	4213	Wheel & tire (See note 1)	Call for price
8A	4228	59 ETC SPDL FLANGE BSHG	$47.34
9	839	BOLT, HEX 3/8 NC X 1 GR5 ZP	$1.54
10	838	WASHER, LOCK, 3/8 ZP	$1.44
11	835	NUT, HEX 3/8 NC ZP	$1.72
12	1972	FITTING, GREASE ZERK 1/4-28	$2.93

Ref: 1 Part #: 2864 Price: $0.99

Item: WASHER, FLAT, 3/4, ZINC-PLT STL

QTY:

Ref: 2 Part #: 4181 Price: $3.75

Item: .781 X 1.00 X .500 HT SLV

QTY:

Ref: 3 Part #: 4207 Price: Call for price

Item: Arm, subassembly

QTY:

Ref: 4 Part #: 1285 Price: $1.44

Item: PIN, COTTER 1/4 X 1-1/2

QTY:

Ref: 5 Part #: 12243 Price: $119.49

Item: 59ETC CASTER YK W/AXLE

QTY:

Ref: 6 Part #: 4212 Price: Call for price

Item: Axle assembly

QTY:

Ref: 7 Part #: 1266 Price: $1.44

Item: PIN, COTTER 3/16 X 1-1/2

QTY:

Ref: 8 Part #: 4213 Price: Call for price

Item: Wheel & tire (See note 1)

QTY:

Ref: 8A Part #: 4228 Price: $47.34

Item: 59 ETC SPDL FLANGE BSHG

QTY:

Ref: 9 Part #: 839 Price: $1.54

Item: BOLT, HEX 3/8 NC X 1 GR5 ZP

QTY:

Ref: 10 Part #: 838 Price: $1.44

Item: WASHER, LOCK, 3/8 ZP

QTY:

Ref: 11 Part #: 835 Price: $1.72

Item: NUT, HEX 3/8 NC ZP

QTY:

Ref: 12 Part #: 1972 Price: $2.93

Item: FITTING, GREASE ZERK 1/4-28

QTY:

WOODS 59C 1 IH FARMALL CUB 59 Casters Assembly
