    WOODS GT72 ROTARY TILLER Frame GT 60 & 72 - SN 580831 And Above Assembly

    WOODS >woods-gt72-rotary-tiller-parts-frame-gt-60-&-72---sn-580831-and-above-assembly
    Ref: 1  Part #: 0101083Y  Price: Call for price

    Item: Pin

    QTY:
    Ref: 2  Part #: 17479  Price: $6.14

    Item: HHCS M12-1.50P X 35MM

    QTY:
    Ref: 3  Part #: 911  Price: $2.10

    Item: SPLIT PIN

    QTY:
    Ref: 4  Part #: 61-1  Price: $3.30

    Item: 12 X 70 SCREW

    QTY:
    Ref: 5  Part #: 325-1  Price: $1.44

    Item: WASHER, 16MM DIA SPRING

    QTY:
    Ref: 6  Part #: 214-1  Price: $1.66

    Item: NUT

    QTY:
    Ref: 7  Part #: 209-1  Price: $1.63

    Item: NUT, 16B MM

    QTY:
    Ref: 8  Part #: 1400085  Price: $10.47

    Item: SPACER

    QTY:
    Ref: 9  Part #: 2002053  Price: $127.37

    Item: L.H. SIDE FRAME

    QTY:
    Ref: 10  Part #: 2002052  Price: $127.48

    Item: R.H. SIDE FRAME

    QTY:
    Ref: 11  Part #: 62542  Price: $2.31

    Item: HHCS, M12-1.75P X 30MM CL8.8

    QTY:
    Ref: 12  Part #: 323-1  Price: $1.17

    Item: WASHER, DIA 12

    QTY:
    Ref: 13  Part #: 221-1  Price: $3.04

    Item: 12 X 1.5 ALTO NUT

    QTY:
    Ref: 14  Part #: 1196  Price: $12.24

    Item: U-BOLT 51 X 72

    QTY:
    Ref: 15  Part #: 106-1  Price: $2.69

    Item: 10 X 35 SCREW

    QTY:
    Ref: 16  Part #: 167-1  Price: $5.79

    Item: 14 X 1.5 X 60 SCREW

    QTY:
    Ref: 17  Part #: 43104  Price: $1.72

    Item: NUT HEX M14 X 1.5

    QTY:
    Ref: 18  Part #: 1400044  Price: $10.56

    Item: CHAIN HOOK

    QTY:
    Ref: 19  Part #: 122-1  Price: $4.79

    Item: 16 X 50 SCREW

    QTY:
    Ref: 20  Part #: 606-1  Price: $6.78

    Item: 90 I LOCKRING

    QTY:
    Ref: 21  Part #: 602  Price: $2.63

    Item: 35 E LOCKRING

    QTY:
    Ref: 22  Part #: 8600050  Price: $38.83

    Item: PLATE

    QTY:
    Ref: 23  Part #: 8600051  Price: $13.00

    Item: SPACER

    QTY:
    Ref: 24  Part #: 1415007  Price: $183.70

    Item: Right upper support

    QTY:
    Ref: 24  Part #: 8616007  Price: $305.93

    Item: R.H. UPPER SUPPORT

    QTY:
    Ref: 25  Part #: 81-1  Price: $2.37

    Item: 10MM X 25MM SCREW

    QTY:
    Ref: 26  Part #: 21542  Price: $0.99

    Item: WASHER, LOCK 10MM

    QTY:
    Ref: 27  Part #: 800057  Price: $230.93

    Item: BASE

    QTY:
    Ref: 28  Part #: 202-1  Price: $2.10

    Item: M12A NUT

    QTY:
    Ref: 29  Part #: 2301045  Price: $188.25

    Item: SIDE FRAME, RH - GT60/72

    QTY:
    Ref: 30  Part #: 201-1  Price: $1.54

    Item: 10 ALTO NUT

    QTY:
    Ref: 31  Part #: 801094  Price: $26.07

    Item: Bracing

    QTY:
    Ref: 33  Part #: 304-1  Price: $1.54

    Item: 14 WASHER

    QTY:
    Ref: 34  Part #: 324-1  Price: $1.54

    Item: 14MM DIA SPRING WASHER

    QTY:
    Ref: 36  Part #: 150-1  Price: $6.50

    Item: SCREW M12 - 1.5 X 90MM

    QTY:
    Ref: 37  Part #: 303-1  Price: $1.35

    Item: 12 WASHER

    QTY:
    Ref: 38  Part #: 2200058  Price: $135.54

    Item: LIFT ATTACHMENT

    QTY:
    Ref: 39  Part #: 0801054C  Price: Call for price

    Item: Guard

    QTY:
    Ref: 40  Part #: 2800081Y  Price: $49.47

    Item: PIN

    QTY:
    Ref: 41  Part #: 815001  Price: $672.80

    Item: Frame

    QTY:
    Ref: 41  Part #: 8718001  Price: $711.40

    Item: Frame

    QTY:
    Ref: 42  Part #: 85-1  Price: $3.42

    Item: SCREW - 10 MM X 65 MM DIN 933

    QTY:
    Ref: 43  Part #: 354  Price: $1.88

    Item: 10 HARDENED WASHER

    QTY:
    Ref: 44  Part #: 805046  Price: $218.67

    Item: SIDE FRAME, LH GT40/52

    QTY:
    Ref: 45  Part #: 247-1  Price: $2.22

    Item: 10 TRIBLOCK NUT

    QTY:
    Ref: 46  Part #: 302-1  Price: $1.17

    Item: 10MM DIA WASHER

    QTY:
    Ref: 47  Part #: 244-1  Price: $4.51

    Item: 10 BASSO NUT

    QTY:
    Ref: 48  Part #: 800087  Price: $8.48

    Item: 11 X 55 WASHER

    QTY:
    Ref: 49  Part #: 2000035  Price: $29.41

    Item: CHAIN TIGHTENER SPRING

    QTY:
    Ref: 50  Part #: 2300034  Price: $62.67

    Item: CHAIN TIGHTENER

    QTY:
    Ref: 51  Part #: 105-1  Price: $2.22

    Item: 10MM X 30MM SCREW

    QTY:
    Ref: 52  Part #: 104-1  Price: $2.22

    Item: 10MM X 20MM SCREW

    QTY:
    Ref: 53  Part #: 801025  Price: $133.20

    Item: UPPER SPROCKET

    QTY:
    Ref: 55  Part #: 2300900  Price: $324.55

    Item: CHAIN

    QTY:
    Ref: 56  Part #: 2300027  Price: $159.14

    Item: LOWER SPROCKET

    QTY:
    Ref: 57  Part #: 603-1  Price: $3.23

    Item: 40 E LOCKRING

    QTY:
    Ref: 58  Part #: 2000029  Price: $81.85

    Item: OIL SEAL COVER

    QTY:
    Ref: 59  Part #: 2300024  Price: $66.98

    Item: GASKET

    QTY:
    Ref: 60  Part #: 2300022  Price: $230.76

    Item: CHAIN HOUSING

    QTY:
    Ref: 61  Part #: 813-1  Price: $4.31

    Item: OIL FILL PLUG (PLASTIC)

    QTY:
    Ref: 62  Part #: 801  Price: $6.82

    Item: OIL LEVEL PLUG (PLASTIC)

    QTY:
    Ref: 63  Part #: 1400050  Price: $23.18

    Item: ROD

    QTY:
    Ref: 64  Part #: 2000041  Price: $103.91

    Item: SKID LH

    QTY:
    Ref: 65  Part #: 2000040  Price: $103.91

    Item: SKID RH

    QTY:
    Ref: 66  Part #: 20890  Price: $42.01

    Item: BEARING, BALL 32 X X72MM

    QTY:
    Ref: 67  Part #: 541  Price: $8.85

    Item: OIL SEAL

    QTY:
    Ref: 68  Part #: 2300029  Price: $380.90

    Item: ROTOR GEARBOX

    QTY:
    Ref: 69  Part #: 2000030  Price: $45.05

    Item: ROTOR COVER

    QTY:
    Ref: 70  Part #: 8715302  Price: $1,494.15

    Item: ROTOR SHAFT - GT60

    QTY:
    Ref: 70  Part #: 8718302  Price: $2,034.78

    Item: ROTOR SHAFT - GT72

    QTY:
    Ref: 71  Part #: 1044450  Price: $3.13

    Item: FITTING - GREASE M10 X 1, STR

    QTY:
    Ref: 72  Part #: 815003  Price: $521.20

    Item: REAR SHIELD

    QTY:
    Ref: 72  Part #: 818003  Price: $435.80

    Item: Rear shield

    QTY:
    Ref: 74  Part #: 2000033  Price: $18.02

    Item: CHAIN

    QTY:
    Ref: 75  Part #: 2000036  Price: $16.03

    Item: SPRING EXT 0.7 .16 2.75 80

    QTY:
    Ref: 76  Part #: 1302178  Price: $21.34

    Item: SPEED TINE, LH

    QTY:
    Ref: 77  Part #: 1302177  Price: $21.34

    Item: SPEED TINE, RH

    QTY:
    Ref: 78  Part #: 154-1  Price: $8.67

    Item: TINE BOLTS

    QTY:
    Ref: 79  Part #: 1302180  Price: $22.22

    Item: L.H. ANGULAR BLADE

    QTY:
    Ref: 80  Part #: 1302179  Price: $22.22

    Item: R.H. ANGULAR BLADE

    QTY:
    Ref: 82  Part #: 338  Price: $1.54

    Item: 10 X 30 WASHER

    QTY:
    Ref: 86  Part #: 450-1  Price: $46.99

    Item: BEARING

    QTY:
    Ref: 87  Part #: 532-1  Price: $11.93

    Item: OIL SEAL

    QTY:
    Ref: 88  Part #: 9200050  Price: $120.47

    Item: JACKSTAND

    QTY:
    Ref: 89  Part #: 800051  Price: $122.51

    Item: JACKSTAND MOUNTING BRACKET

    QTY:
    Ref: 90  Part #: KTDWGT60  Price: $62.59

    Item: Decal set, GT60

    QTY:
    Ref: 91  Part #: KTDWGT72  Price: $103.45

    Item: DECAL SET CMPL GT72
