Item: Muffler Shield

Item: Muffler With Deflector

Item: Deflector

Item: Clamp With Hardware

Item: Exhaust Pipe

Item: Centrifugal drive clutch

Item: 1 x 1-1/4 x 13/16 Sleeve

Item: Gasket

Item: 10hp Briggs & Stratton vertical crank engine

Item: Throttle control assembly

Item: 3/8 x 3 Pipe nipple

Item: 3/8 Pipe coupler

Item: Right belt shield

Item: Tank Shield Assembly

Item: Center shield door

Item: Fuel tank 4 gallon

Item: Gas tank strap

Item: 1/8 x 1/8 NPTF steel street ell

Item: 1/8 NPTF x 7 pipe nipple

Item: 1/8 x 1/8 NPTF fuel valve

Item: 1/8 NPTF x 1/4 hose coupling

Item: 1/4 ID gasoline hose, 9 inch long

Item: Left belt shield assembly

Item: Blade wrench

Item: 1/4 SCDL 40 pipe 2-5/8 long

Item: Decal set

Item: No 10 x 1/4 Pan Head tapping screw (See note 1)

Item: No 6 x 1/2 tap screw (See note 2)

Item: 1/4 X 1/4 X 1-1/4 KEY

Item: BOLT, HEX, 1/4NC X 3/4, GR5

Item: WASHER, FLAT 1/4

Item: 1/4 NC deformed thread nut (See note 6)

Item: 5/16 NC x 3/4 HHCS Grade 8 (See note 7)

Item: BOLT, HEX 5/16 NC X 3/4 SELF TAPPING

Item: 5/16 NC x 1-1/2 Hex head cap screw (See note 9)

Item: 5/16 NC x 3-1/2 Hex head cap screw (See note 10)

Item: WASHER, LOCK 5/16

Item: WASHER, FLAT SAE 5/16

Item: NUT, HEX 5/16 NC

Item: 3/8 NC x 3/4 Carriage bolt (See note 14)

Item: NUT, LOCK FLANGE 3/8 NC
